Performance
- First Target Priority feature confirms measurement is to first flag, not background objects
- Eight-second continuous measurement for scanning range to hazards, trees, pins, etc.
- Adjustable diopter for focusing display
Use and Handling
- 6x magnification
- 20mm objective lens
- Measurement range: 6-800 yards
- Measurement accuracy: ±1yard/meter to 100 yards/meters, ±2 yards/meters beyond
- Display in 1-yard/meter increments
- 315' field of view at 1000 yards
- 6° actual angle of view
- Knurled focus collar
- Automatic power-off after eight seconds of inactivity
- 16.7mm long eye relief
Construction
- Anti-reflection multi-coated optics
- Roof prism design
- Class 1M laser
- IPX4-rated water resistant
- Runs on one CR2 coin-cell battery
- Broad 14 to 122°F operating temperature range
- Lightweight at 4.6 oz
The device has a measurement accuracy of ±1 yard/meter out to 100 yards/meters and ±2 yards/meters beyond that, and it displays distance in yards or meters on a high-visibility display. Diopter adjustment makes it easy to lock the display into focus. The 6x magnification is suitable for identifying targets at mid-range distances, and a long eye relief helps eyeglass wearers use it comfortably. Multi-coated optics, weatherproof construction, a wide temperature tolerance, and one-touch activation make this rangefinder dependable and easy to use.
Laser
Laser Type Class 1M Eye Safe
Metering Range 6 to 800 yd / 5.49 to 731.52 m
Accuracy < 1 to 100 yd / 0.91 to 91.44 m: ±1 yd / 0.91 m
100 to 800 yd / 91.44 to 731.52 m: ±2 yd / 1.83 m
Peak Wavelength 905 nm
Optics
Prism Type Roof
Magnification 6x
Objective Lens Diameter 20 mm
Angle of View 6° (Actual)
Field of View 315' @ 1000 yd / 104.58 m @ 1000 m
Exit Pupil Diameter 3.3 mm
Eye Relief 16.7 mm
Dioptric Correction ±4
General
Form Factor Monocular
Power Source 1 x CR2
Inclinometer None
Physical
Water Resistance Water Resistant, IPX4
Operating Temperature 14 to 122°F / -10 to 50°C
Dimensions 3.6 x 2.9 x 1.5" / 9.14 x 7.37 x 3.81 cm
Weight 4.6 oz / 130.0 g
