Shake-Free Vision - anywhere, anytime
Combines SWAROVSKI OPTIK’s legendary optical quality with our cutting edge stabilization technology.
Instant Clarity, Immediate Results - Delivers sharp stabilized images the moment you raise it. No setup
Steady Vision
Comfortable stabilization with exceptionally low image latency keeps your view perfectly stable
True Handheld Freedom
No tripod, no extra weight, no restrictions
SWAROBALANCE: Shake Free Image Stabilization even at high magnification and in challenging conditions
SWAROVISION: Field flattener lenses deliver distortion free image definition right to the edges, high contrast true-to-life images and excellent color rendering
Powered by a rechargeable battery, up to 12 hours of operation (at room temperature)
The AT/ST Balance spotting scopes have a moving lens that is adjusted by an electric motor (voice coil motor) to offset movements. These motors work particularly quickly, very pre cisely, and with low friction – the pushing and pulling move ments are smooth and continuous. They are also used in ap plications such as camera autofocus systems. The integrated gyroscope sensor measures the current move ment of the spotting scope. Based on this, a calculation is made to determine which lens movement is necessary to com pensate for the motion to result in a stable image. With the stabilization concept of the AT/ST Balance also in movement there is no perceptible “floating” or “after-image”, which is key to the unique natural sense of vision. Automatic locking of the moving lens in the event of a fall or a sudden interruption in the power supply protects the lens while also ensuring the best optical quality by keeping the lens in the central position
Magnification: 18-45x
Effective objective lens diameter (mm) 65
Exit Pupil Diameter (mm) 3.4-1.4
Exit Pupil Distance (mm) 20
Field of View (m-1,000m/ft/1,000 yds) 55-30/165-90
Field of View (degrees) 3.16-1.74
Field of View, apparent (degrees) 57-71
Shortest Focusing Distance (m/ft) 3.4/11.2
Diopter correction at ∞ (dpt) >5
Light Transmission (%) 88
Objective Filter Thread M72x0.75
Dimensions LxWxH (mm/in) 268x83x148 / 10.6x3.3x5.8
Approx. Weight (g/oz) 1470 / 51.9
