AT A GLANCE

• 1-Person Interviews, Videos, Streaming
• Connects to Cameras, iOS/Android Devices
• 1 x Clip-On Transmitter/Recorder Mic
• Compact Receiver, 4-Channel Output
• Two-Level Noise Cancellation Modes
• 32-Bit Float Recording, Timecode Support
• AMOLED Touchscreen, Onboard Controls
• Up to 1312' Wireless Range
• Dual-Band Wireless and Bluetooth 5.4
• Built-In Rechargeable Batteries

High-Quality Audio with Flexibility for Postproduction

• The compact receiver connects to your camera via 3.5mm TRS port and included adapter cable. An included USB-C adapter can plug the receiver into a compatible mobile device. It supports timecode input and output for improved sync of your video and audio.
• The transmitters embed timecode data into its internal recording files for efficient postproduction workflow. Dual-file recording saves both an original track and algorithm-enhanced version. The transmitters support 32-bit float recording and Lossless Audio modes for greater control over your audio files.

Adaptive Gain Control

Toggle between two different gain modes for adaptive control over your audio recording. Automatic mode prevents audio clipping and is especially useful when you anticipate loud interferences. Dynamic mode adjusts gain in response to volume changes for consistency, which is ideal for more predictable settings.

Voice Presets and Two-Level Noise Cancellation

Further customize your sound with three voice presets—regular, rich, and bright—depending on the tone you'd like to achieve. Two-level noise cancellation helps anticipate additional disruption. Basic noise cancellation reduces low, droning sounds like fans and air-conditioning. Strong noise cancellation is designed for noisy environments, significantly cutting ambient noise.

Effortless Control

A 1.1" AMOLED touchscreen and dial control on the receiver allows you to adjust and view parameters such as gain, battery status, and mode. Use the DJI Mimo app to further fine-tune settings and facilitate firmware updates to the system.

Flexible Channel Settings

Like typical wireless systems, the DJI Mic 3 receiver allows you to choose between mono and stereo recording modes. Where the new system expands upon its predecessor is the ability to expand your audio ecosystem. In Quadraphonic mode, the receiver, in tandem with select Sony cameras and computer software and using the separately available camera adapter, can output four audio tracks for flexible mixing. While this system includes two transmitters and one receiver, the receiver itself can support up to four transmitters at one time. It can also sync audio to seven additional receivers for a virtually infinite wireless array useful in group interview or multi-camera productions.

Dual-Band Wireless, Bluetooth Connectivity

The DJI Mic 3 system supports dual-band wireless frequency hopping between 2.4 and 5.8 GHz signals from up to 1312' away. Bluetooth 5.4 technology is also integrated into the system for connectivity with your mobile device. The transmitter units can directly connect to DJI Osmo 360, Osmo Action 5 Pro, Osmo Action 4, or Osmo Pocket 3 without a receiver.

Long Battery Life, Charging Case

Internal batteries on the receiver and transmitter units keep the system all day. Power-saving features on each component like automatic sleep mode, automatic power off, and simultaneous use while charging your smartphone help stretch this battery life even further. The included charging case stores all of the components inside and extends the system's total battery life up to 28.

Wireless Technology  Digital 2.4 GHz / Digital 5.8 GHz / Bluetooth

Diversity  Non-Diversity

RF Frequency Band  2400 to 2486 MHz / 5150 to 5250 MHz / 5250 to 5350 MHz / 5470 to 5725 MHz / 5725 to 5850 MHz

Max Operating Range  1312.3' / 400 m (Line of Sight)
                                     262.5' / 80 m (with Obstruction)

Max Transmitters per Band  4

Built-In Recorder  Yes (on Transmitter)

Timecode Support  Yes

Mobile App Compatible  Yes: Android & iOS
                                       App Name: DJI Mimo

Receiver Type  1x Camera-Mount

Mounting Options  Shoe-Mount (with Included Hardware)
                              USB-C Plug-In (with Included Adapter)

Antenna  1x Internal

Number of Audio Channels  2

Audio I/O  1x 1/8" / 3.5 mm TRS Unbalanced Output

USB/Lightning Connectivity  1x USB-C Female

Display  OLED

Power Requirements  Battery

Included Transmitters  2x Clip-On with Microphone

Antenna  Internal

Input Level  Line

Audio I/O  No

Bias/Plug-In & Phantom Power  No Bias/Plug-In Power
                                                   No Phantom Support

USB I/O  No

Muting  No

Auto-Level/Gain  Yes

Sync Method  2.4 GHz QPSK

Display  Single-LED Indicators Only

Microphone Type  1x Built-In (Clip-On Transmitter)

Polar Pattern  Omnidirectional

Maximum SPL  126 dB

Sensitivity  -36 dBV (@ 1 kHZ, 94 dB SPL)

Color  Black

Receiver Battery Type  1x Built-In Rechargeable - 275 mAh

Receiver Battery Life  10 Hours

Transmitter Battery Type1x Built-In Rechargeable - 137 mAh

Transmitter Battery Life  8 Hours

Battery Charging Time  50 Minutes

Additional Runtime with Charging Case  28 Hours

Quick Charging Times  5 Minutes for 2 Hours

Battery  1950 mAh Rechargeable

Recharge Time  1.5 Hours

Charging Input  USB-C

Input Power  5 VDC at 1.5 to 2 A

Dimensions

Receiver:  2.1 x 1.1 x 0.9" / 53.9 x 28.7 x 22 mm
Transmitter:  1.1 x 1.1 x 0.6" / 28.8 x 28.3 x 16.4 mm

Weight

Receiver:  0.9 oz / 25.1 g
Transmitter:  0.6 oz / 16 g
