AT A GLANCE
An ultimate hybrid camera, featuring LUMIX Color Science, wide dynamic range x 24M x high-speed, allowing the creators to efficiently capture photos and videos just as they envision.
• High frame rate video /wide dynamic range (4K120p, 5.1K60p, 15 stops of dynamic range, LUMIX color science)
• Burst shooting photos / high quality images (70fps SH+ burst shooting, 1.5sec Pre burst, HEIF)
• Shooting efficiency (Phase Hybrid AF with AI, image stabilizer, burst shooting, REAL TIME LUT)
• Workflow efficiency (LUMIX Lab/Flow, Capture One, Frame.io, loading settings between different models)
• Creating diverse images (Open Gate, LUT, Cinelike A2, Internal RAW)
• Superb operability (Photo/Video/S&Q switch, tilt and free-angle rear monitor, view finder, Hybrid/Crop Zoom)
• High quality audio recording with 32-bit float recording
Type Digital Single Lens Mirrorless camera
Lens mount L-Mount
IMAGE SENSOR Type 35mm full-frame (35.8mm x 23.8mm) CMOS sensor
Camera effective pixels / Total pixels 24.1 megapixels / 26.8 megapixels
AR (Anti Reflection) coating Yes
Aspect ratio / Color filter 3:2 / Primary color filter
Dust reduction system Image sensor shift type
Shutter Behavior at Power Off ON / OFF
LATITUDEÂ 15 stops (V-Log) (Dynamic Range Boost ON)
          14+ stops (V-Log) (Dynamic Range Boost OFF)
STILL IMAGE Recording file format JPEG (DCF, Exif 3.0), RAW, HEIF
Aspect ratio 4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1Â
Image quality Fine, Standard
HDR (HLG) Yes
Color space sRGB, AdobeRGB
View Finder Type OLED Live View Finder
Pixels Approx. 5.76 million dots
Field of view / Magnification  Approx. 100% / Approx. 0.78x with 50 mm lens at infinity; -1.0 m-1, when the aspect ratio is set to 3:2
Eye point / Diopter adjustment Approx. 21 mm at infinity; -1.0 m-1 / -4.0 - +2.0 (dpt)
Eye sensor Yes
Display speed 120fps* / 60fps    *During live view in photo recording mode.
Type TFT LCD monitor with static touch control
Monitor size Tilt free-angle, 3.0-inch (7.6cm), 3:2 aspect
Pixels Approx. 1.84 million dots
Field of view Approx. 100%
Type Phase Detection AF system (779-point) / Contrast AF system (315-area)
DFD technology Yes
Focus mode AFS (Single) / AFC (Continuous) / MF
AF modeTracking / Full Area AF / Zone (Horizontal/Vertical) / Zone / 1-Area+ / 1-Area / Pinpoint
*Automatic Detection can be turned ON to switch between Human / Animal / Car / Motorcycle/Bike / Train / Airplane. Except when Pinpoint is set. Target Parts can also be set.
AF detective range EV -6 - 18 (F1.4, ISO100 equivalent, AFS)
AF custom setting AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction
AF assist light Yes
AF lock Set the Fn button in custom menu to AF lock
Focus ring control Nonlinear / Linear (90°/ 120°/ 150°/ 180°/ 210°/ 240°/ 270°/ 300°/ 330°/ 360°/ 720°/ 1080°/ Maximum)
Direction of ring rotation: Forward and reverse selectable
Others AF-ON, AF-ON: Near Shift, AF-ON: Far Shift, Focus Limiter, Focus Peaking, Focus Frame Moving Speed, Focus/Shutter Priority, Focus Switching for Vert/Hor, AF/AE Lock Hold, AF+MF, MF Assist, MF Guide, Focus Ring Lock, Show/Hide AF Mode, AF-Point Scope, Shutter AF, Half Press Shutter, Quick AF, Eye Sensor AF, Loop Focus Frame, Enlarged Live Display (Video), AFS Behavior in Video Mode, Touch Shutter, Touch AF/AE Function, Touch Pad AF, Lens Focus Resume, AF Micro Adjustment
Light metering system 1,728-zone multi-pattern sensing system
Light metering mode Multiple / Center Weighted / Spot / Highlight Weighted
Metering range EV0-18 (F2.0 lens, ISO100 equivalent)
Recording mode Mode dial Program AE (P) / Aperture Priority AE (A) / Shutter Priority AE (S) / Manual Exposure (M) / Custom 1, 2, 3, 4, 5 / Intelligent Auto
Photo/Video/S&Q switch Photo Mode / Video Mode / Slow&Quick Mode
Custom mode The settings can be registered for each of the photo, video, and S&Q modes.
Exposure compensation 1/3 EV step ±5EV (±3EV for motion picture)
White balance AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4
             AI-AWB can be set when RAW processing.
White balance adjustment Blue/Amber bias, Magenta/Green bias
Color temperature setting 2500-10000K in 100K
Type Focal-plane shutter
Silent mode / Shutter type Yes / Yes (Auto / Mechanical / Electronic front curtain / Electronic / Electronic+NR)
Shutter speed Still image: Bulb (Max. 30 minutes), 1/8,000 - 60
            Electronic front curtain shutter: Bulb (Max. 30 minutes), 1/2,000 - 60
            Electronic shutter: Bulb (Max. 60 sec), 1/16,000 - 60
            Motion picture: 1/16,000 - 1/25* (Dynamic Range Boost OFF)
            Motion picture: 1/6,400 - 1/25* (Dynamic Range Boost ON)
            Motion picture M mode / MF mode: 1/16,000 - 1/25* (Dynamic Range Boost OFF)
            Motion picture M mode / MF mode: 1/6,400 - 1/25* (Dynamic Range Boost ON)
           *Can be set up to 1/2 of a second when exposure is M and focus mode is MF in video mode.
Self timer 10sec, 3 images / 2sec / 10sec / Custom Time
Remote control Remote control by DMW-RS2 (sold separately)
AE bracket 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst
Aperture bracket 3, 5 or all positions
Focus bracket Yes
White balance bracket 3 images in blue/amber axis or in magenta/green axis, color temperature setting
Flash type Sold separately
Synchronization speed Less than 1/250 second    *The guide number decreases at 1/250 second. Only when set to M mode or S mode.Â
Flash mode Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced Off    *For iA only.
Flash output adjustment 1/3EV step ±3EV
Flash synchronization 1st Curtain Sync, 2nd Curtain Sync.
Wireless control Yes (When using DMW-FL200L / FL360L / FL580L (sold separately)), Wireless Channel: 1ch/2ch/3ch/4ch
USB USB Type-C® (USB 10Gbps)
HDMI (*6)Â HDMIHDMI TypeA
Audio: ON / OFF, MP4: 2ch, MOV: 2ch (When [4ch Mic Input] is set to OFF.), 4ch (When [4ch Mic Input] is set to ON.)
Monitor-through 4:2:2 10bit (When [Rec Quality] is set to [4:2:2 10bit] or [4:2:0 10bit].)
              4:2:2 8bit (When [Rec Quality] is set to [4:2:0 8bit].)
              Down Convert: Auto / C4K/4K / 1080p / 1080i / OFF
Playback 59.94Hz: C4K/120p / C4K/60p / C4K/30p / 4K/120p / 4K/60p / 4K/30p / 1080/120p / 1080p / 1080i / 720p* / 480p*
         50.00Hz: C4K/100p / C4K/50p / C4K/25p / 4K/100p / 4K/50p / 4K/25p / 1080/100p / 1080p / 1080i / 720p* / 576p*
         24.00Hz: C4K/120p / C4K/24p / 4K/120p / 4K/24p / 1080/120p / 1080p
        *Only for playback.
Remote input φ2.5mm
Audio Built-in microphone Stereo
Wind Noise Canceller: OFF / Standard / High
External microphone / External audio device inputφ3.5mm for external microphone / external audio device
MIC (Plug-in Power) / MIC / LINE
Wind Cut: OFF / Low / Standard / High    *When attaching 3.5mm microphone (sold separately).
Special Mic: Stereo / Shotgun    *When attaching DMW-MS2 (sold separately).
XLR microphone Yes with DMW-XLR2 (sold separately)
4ch mic input Yes with DMW-XLR2 (sold separately)
Speaker Monaural
Headphone output φ3.5mm
Card slot  Slot 1: CFexpress Type B Card
         Slot 2: SD Memory Card / SDHC Memory Card* / SDXC Memory Card*
        *Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.
Battery Li-ion Battery Pack (7.2V, 2200mAh, 16Wh) (bundled)
USB power supply, USB power charging, USB power delivery
Battery life (CIPA standard)When using CFexpress CardApprox. 350 images (rear monitor), 310 images (LVF), 1,000 images (Power Save LVF mode*) with S-R24105 / DMW-BLK22
*Using a Nextorage CFexpress Type B card. Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
When using SD memory cardApprox. 360 images (rear monitor), 320 images (LVF), 1,150 images (Power Save LVF mode*) with S-R24105 / DMW-BLK22
*Using a Nextorage SDXC memory card. Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
Dimensions (W x H x D)Â Â Approx. 134.3 x 102.3 x 91.8 mm / 5.29 x 4.03 x 3.61 inch (Body only, excluding protrusions)
                   Â
Weight   Approx. 800g / 1.76 lb (Body, Hot Shoe Cover, Battery, SD Memory Card x 1) (excluding body cap)
        Approx. 718g / 1.58 lb (Body, Hot Shoe Cover) (excluding body cap)
