AT A GLANCE
Â
- Maximum Load 6kg
- Safety Lock System
- 90mm Quick Release Plate Slide
- 360° Panorama Panning
- 2 x Bubble Levels
Â
DESCRIPTION
With a maximum load of 6kg, this fluid-damped video tilt head is designed for DSLRs and video cameras. Thanks to the fluid damping system with separate control for pan, a smooth, quiet and vibration-free camera use is possible.
The friction of the tilt movement can be continuously adjusted. The pan movement can be locked and the pan friction can be adjusted in 4 stages. The head operates exceptionally smoothly and can be precisely adjusted. It is intuitive to operate and direct. The Safety Lock System prevents the release plate from accidentally slipping.
Â
- Spirit levels are located on the top and bottom for precise alignment.
- 3 stage friction control for panning, plus a 0 position with no friction
- Sophisticated fluid damping system allows vibration-free use
- Safety Lock System - prevents the plate from accidentally slipping
- Continuously adjustable friction for tilt
- 360° panorama panning
- 2 spirit levels
- Rubber covered handle - extends from 30cm to 47cm
- Sliding release plate (90mm) with 1/4 inch and 3/8 inch thread
- Compatible for video tripods with a head surface area of at least 65mm
- Tripod connection: 3/8 inch thread
Â
SPECIFICATIONS
Tilt -65° to +90°
Counterweight 2kg
Quick release plate slide 90mm
Base plate diameter 65mm
Handle length from 30cm to 47cm
Material Aluminium
Max. load 6kg
Size LxWxH (with handle) 93 (370) x 145 x 96mm
Weight 920g
